KOYO bearings 32210JR tapered roller bearings wanted-Choose Tapered Roller Bearings Manufacturer

KOYO bearings 32210JR tapered roller bearings

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!

Description

Technical

Application

Pictures

1.Taper roller bearing are generally used to support combined load mainly consisting of radial load. Their cups are separable for easy assembling. During mounting and using, radial clearance and axial clearance can be adjusted and mounting can be made.Taper roller bearing are uniquely designed to manage both thrust and radial loads on rotating shafts and in housings.Taper roller bearing are designed to carry both thrust and radial loads and consist of four components: the cone, or inner ring; the cup, or outer ring; the tapered rollers, or rolling elements; and the cage, or roller retainer.

2.Taper roller bearing mainly carry radial, axial combined load with radial load in the main. The capacity of axial load carrying depends on the contact angle of outer ring’s raceway. The bigger the contact angle is, the greater the capacity will be.Taper roller bearing the angle between the outer raceway and line, the bearing can bearing heavy load and other Tapered Roller Bearings, it mainly bears joint load based on one way axial load,but not only radial load.

Product name	Taper roller bearing
Brand name	KOYO
Original Packing	(a)Neutral package & wooden package
	(b)Carton /Wooden package+pallet(fumigation-free)
	(c)As customer request
Precision	P2/P4/P5/P6/P0
Material	GCR-15 chrome steel,Bearing Steel
Quality standard	ISO9001:2000
Place of original	China
Delivery date	Within 5 working days or according to you request
Payment terms	A:100% T/T in advance
	B:30%T/T in advance.70% against copy of B/L
	C:Western Union
Features	these bearings are featured by the extremely big axial load carrying capacity
Features	and meanwhile,they can also carry certain radial load
Package detail	single box/industrial standard packing/single carton/according to buyers requirement
Cage Material	Bearing steel/brass
Main market	Mideast;Canada;Southeast Asia;South America and other countries all over the world

Bearing Model	d(mm)	D(mm)	B(mm)	Weight(kg)
30202	15	35	11	0.053
30203	17	40	12	0.079
30204	20	47	14	0.126
30205	25	52	15	0.154
30206	30	62	17.5	0.231
30207	35	72	17	0.331
30208	40	80	18	0.422
30209	45	85	19	0.474
30210	50	90	20	0.529
30211	55	100	21	0.713
30212	60	110	22	0.904
30213	65	120	23	1.13
30214	70	125	24	1.26
30215	75	130	25	1.36
30216	80	140	26	1.67
30217	85	150	31	2.06
30218	90	160	30	2.54
30219	95	170	32	3.04
30220	100	180	34	3.72
