SYBR 399A/394A Sealed Tapered Roller Bearings

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!

Description

Technical

Application

Pictures

Sealed Tapered Roller Bearing Details:

SYBR taper roller bearings have taper inner and outer ring raceways and taper rollers. They are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads. The projection lines of the raceways meet at a common point on the bearing axis to provide true rolling and low friction. The axial load carrying capacity of auto taper roller bearings increases with increasing contact angle (α). The size of the angle is indicated by the calculation factor e: the larger the value of e, the larger the contact angle. A single row taper roller bearing is typically adjusted against a second tapered roller bearing.Single row taper roller bearings are separable i.e. the inner ring with roller and cage assembly (cone) can be mounted separately from the outer ring (cup).

Product	68.262x110x79.045 mm Sealed taper roller bearing 399A/394A
Precision Rating	ABEC1,ABEC3,ABEC
Clearance	C0,C2,C3,C4,C5 is available
Sealed Cap	Rubber or Metal
Paypal	Acceptable
OEM	Accept
Vibration Level code	V1,V2.V3
Material	Gcr15
Seals Type	ZZ/ZRS.RZ/RS. Open
Bore Size Outside Diameter Thinckess	68.262 MM 110.0 MM 79.0 mm
Number of Row	Double
Regular export packing	Plastic drum+White box+ carton
	industrial packaging or as your requiremen.
MOQ	1 pcs
Delivery Time	3-7 days after receiving your payment
Payment Terms	L/C,T/T,Western Union,MoneyGram,Paypal
Port of shippment by sea	Shanghai,guangzhou,qingdao
Place of Origin	Shandong
Samples	OK

Shipping and Delivery:

Bearings Package:

Original Package:

1):Inner Plastic Bag+ Paper Box + Carton(+Pallet);

2):Small sizes:Plastic Tube + Carton

3):Big sizes:Wooden Case

Bearings Lead time:

We will prepare your order as soon as possible.

1)2-3 days for ex-stock

2)6-10 days for others

Shipping & Delivery time:

1)Less than 45 Kg:DHL TNT Fedex UPS express will be better,( 4-7 days delivered to your address);

2) Between 45 to 200 Kg:Air transiportation will be better,( 5-14 days delivered to your airport);

3) Over 200 Kg:Sea transportation will be better.( Cheapest,18-45 days to your port ).

Note:We will offer the best freight for you to save the shipping cost.Besides we provide all needed documents for your Customs clearance.Of course,your forwarder will be also welcome!

SET Tapered Roller Bearings Catalog:

Modle	D(mm)	d(mm)	B(mm)
12168 12303	76.992	42.862	17.145
26884R 26822	79.375	42.875	25.4
25577 25520	82.931	42.875	25.4
L102849 L102810	73.025	44.45	18.258
12175 12303	76.992	44.45	17.145
18685 18620	79.375	44.45	17.462
25582 25520	82.931	44.45	25.4
3578R 3520	84.138	44.45	30.886
355 354A	85	44.45	21.692
355A 354A	85	44.45	21.692
HM803149 HM803110	88.9	44.45	29.37
49175 49368	93.662	44.45	31.75
46175 46368	93.662	44.45	31.75
46176 46368	93.662	44.45	31.75
33885 33821	95.25	44.45	28.575
438 432A	95.25	44.45	29.901
HM804842 HM804810	95.25	44.45	29.37
HM804843 HM804810	95.25	44.45	29.37
49576 49520	98.425	44.45	31.75
527 522	101.6	44.45	36.068
HM807040 HM807010	104.775	44.45	36.512
535 532A	111.125	44.45	36.957
615 612	120.65	44.45	41.275
3776 3720	93.264	44.983	30.302
358 354A	85	45	21.692
LM102949 LM102910	73.431	45.242	19.812
LM603049 LM603011	77.788	45.242	19.842
LM603049 LM603012	77.788	45.242	19.842
LM603049 LM603014	79.974	45.242	19.842
25590 25526	85	45.618	25.4
LM503349R LM503310	74.976	45.987	18
18690 18620	79.375	46.038	17.462
359A 354A	85	46.038	21.692
359S 354A	85	46.038	21.692
2984 2924	85	46.038	25.608
369A 362A	88.9	47.625	22.225
M804049 M804010	88.9	47.625	25.4
HM804846 HM804810	95.25	47.625	29.37
386A 382A	96.838	47.625	21.946
528 522	1.6	47.625	36.068
463 453X	4.775	47.625	29.317
467 453X	4.775	47.625	29.317
45282 45220	4.775	47.625	30.958
HM804848 HM804810	95.25	48.412	29.37
HM804849 HM804810	95.25	48.412	29.37
365S 362A	88.9	49.212	22.225
HM807044 HM807010	4.775	49.212	36.512
65390 65320	14.3	49.212	44.45
HH506348 HH506310	14.3	49.212	44.45
28579R 28521	92.075	49.987	25.4
JLM104948 JLM104910	82	50	21.501
365 362A	88.9	50	22.225
366 362A	88.9	50	22.225
JM205149 JM205110	90	50	28
JHM807045 JHM807012	105	50	36
396 394A	110	50	21.996
L305649R L305610	80.962	50.8	18.258
LM104949 LM104911	82.55	50.8	22.225
18200 18337	85.725	50.8	18.263
18790 18724	88.9	50.8	17.462
368 362A	88.9	50.8	22.225
368A 362A	88.9	50.8	22.225
370A 362A	88.9	50.8	22.225
28580R 28521	92.075	50.8	25.4
375 374	93.264	50.8	22.225
3780 3720	93.264	50.8	30.302
3780 3730	93.264	50.8	30.302
33889 33822	95.25	50.8	28.575
385AX 382A	96.838	50.8	21.946
28678 28622	97.63	50.8	24.608
3780 3732	98.425	50.8	30.302
49585 49520	101.6	50.8	31.75
529 522	101.6	50.8	36.068
529X 522	101.6	50.8	36.068
45284 45220	104.775	50.8	30.958
59200 59412	104.775	50.8	36.512
